Product Features：

• High-precision sensor, accurate counting, excellent performance

• Compact size for convenient installation

• 4.3-inch intelligent touchscreen, rapid response, human-machine interaction, real-time display of monitoring data.

• Can set its own instrument address directly on the screen for easy on-site replacement

• Calibration due alert to remind customers of metering/calibration

• Screen data alarm and real-time flow monitoring. When connected to an independent pump, it automatically adjusts the flow rate in real-time to ensure flow stability and counting accuracy.

• High sampling flow rate of 100L/min enhances sampling precision and efficiency

• 10-year service life imported semiconductor laser diode (calibration required annually)

• RS485 communication, supports Modbus RTU protocol, and customized communication protocols

• Intelligent IoT capabilities allow for remote start/stop, more accurate cleanliness level management, and enhanced monitoring quality

• Expandable analog input hardware interfaces, allowing for external connections to temperature and humidity sensors, airspeed sensors, pressure differential sensors, etc. (optional)

• USB data export functionality, effective local data storage for over a month to prevent data loss (optional)

• Real-time monitoring of particle quantities with particle sizes of 10μm, 50μm, 1000μm, 150μm, 300μm, and 500μm

• Built-in audio-visual alarm light, >85db

• Counter can be equipped with a wireless antenna, upgraded to wireless transmission mode (optional)

Technical Specifications:
